在工業生產的舞臺上，涂裝流水線如同一位技藝精湛的 “彩妝大師”，為各類工件披上色彩斑斕又耐用的外衣?？此茝?fù)雜的涂裝過程，實則遵循一套嚴謹有序的操作流程。從工件入場到成品下線，每一步都環環相扣，共同完成這場工業美學的塑造。

　　On the stage of industrial production, the painting assembly line is like a skilled "makeup master", covering various workpieces with colorful and durable coats. The seemingly complex painting process actually follows a rigorous and orderly operating procedure. From the entry of the workpiece to the production of the finished product, every step is interrelated, jointly completing the shaping of industrial aesthetics.

　　工件預處理：打造完美 “底色”

　　Workpiece pre-processing: Creating a perfect "base color"

　　工件進入涂裝流水線的第一步，便是預處理環節，這就好比化妝前的皮膚清潔，是確保涂層質量的關鍵。首先，要對工件表面進行除油處理。工業生產中，工件表面常殘留加工過程中的潤滑油、防銹油等雜質，若不清除干凈，會嚴重影響涂層附著力。常見的除油方法有溶劑清洗、堿性溶液清洗等，通過化學反應或溶解作用，將油污徹底清除。除油后，需進行除銹工序。無論是鋼鐵工件表面的鐵銹，還是其他金屬表面的氧化層，都要用噴砂、拋丸或化學酸洗等方式去除，使工件露出光潔的金屬表面。最后，進行水洗和干燥，水洗是為了沖掉殘留的清洗液和雜質，而干燥則是確保工件表面無水漬，避免水分導致涂層起泡、脫落。只有經過這一系列精細的預處理，才能為后續涂裝打好基礎。

　　The first step for the workpiece to enter the coating assembly line is the pre-treatment process, which is like skin cleaning before makeup and is the key to ensuring the quality of the coating. Firstly, the surface of the workpiece needs to be degreased. In industrial production, impurities such as lubricating oil and rust proof oil from the machining process often remain on the surface of the workpiece. If not cleaned thoroughly, it will seriously affect the adhesion of the coating. Common oil removal methods include solvent cleaning, alkaline solution cleaning, etc., which thoroughly remove oil stains through chemical reactions or dissolution. After oil removal, a rust removal process is required. Whether it is rust on the surface of steel workpieces or oxide layers on other metal surfaces, they should be removed by sandblasting, shot blasting, or chemical pickling to expose a smooth metal surface of the workpiece. Finally, water washing and drying are carried out. Water washing is used to flush away residual cleaning solution and impurities, while drying is used to ensure that there are no water stains on the surface of the workpiece, avoiding water from causing the coating to bubble or peel off. Only through this series of fine pretreatment can a solid foundation be laid for subsequent painting.

　　底漆噴涂：筑牢防護 “根基”

　　Primer spraying: Building a solid foundation for protection

　　預處理后的工件進入底漆噴涂環節。底漆就像建筑的地基，不僅能增強涂層與工件表面的附著力，還能起到初步防腐的作用。根據工件材質和使用環境的不同，底漆的種類也有所差異。對于金屬工件，常選用環氧底漆，它具有良好的防銹性能和附著力；而對于塑料工件，則會使用專門的塑料底漆，以改善涂層與塑料表面的結合力。底漆噴涂方式多樣，常見的有空氣噴涂、靜電噴涂等?？諝鈬娡客ㄟ^壓縮空氣將涂料霧化并噴射到工件表面，操作靈活，適合各種形狀的工件；靜電噴涂則利用靜電吸附原理，使涂料均勻地吸附在工件表面，能提高涂料利用率和涂層均勻性。噴涂過程中，需嚴格控制噴涂壓力、距離和速度，確保底漆厚度均勻，一般底漆厚度控制在 15 - 30 微米之間。

　　The preprocessed workpiece enters the primer spraying stage. Primer is like the foundation of a building, which not only enhances the adhesion between the coating and the surface of the workpiece, but also plays a preliminary role in corrosion prevention. The type of primer varies depending on the material of the workpiece and the usage environment. For metal workpieces, epoxy primer is often used, which has good anti rust performance and adhesion; For plastic workpieces, specialized plastic primers are used to improve the adhesion between the coating and the plastic surface. There are various ways to spray primer, including air spraying, electrostatic spraying, etc. Air spraying atomizes and sprays paint onto the surface of workpieces through compressed air, which is flexible and suitable for various shapes of workpieces; Electrostatic spraying utilizes the principle of electrostatic adsorption to evenly adsorb the coating onto the surface of the workpiece, which can improve the utilization rate and uniformity of the coating. During the spraying process, it is necessary to strictly control the spraying pressure, distance, and speed to ensure uniform primer thickness. Generally, the primer thickness is controlled between 15-30 microns.

　　中間涂層與面漆噴涂：賦予絢麗 “色彩”

　　Intermediate coating and topcoat spraying: endowing brilliant "colors"

　　底漆干燥后，緊接著進行中間涂層噴涂。中間涂層主要起到填充、找平的作用，進一步提高涂層的平整度和豐滿度，同時增強涂層的防護性能。中間涂層的涂料通常具有較好的打磨性，噴涂完成并干燥后，需進行打磨處理，消除表面的顆粒、流痕等缺陷，為面漆噴涂創造光滑的表面。打磨后的工件進入面漆噴涂工序，這是賦予工件最終色彩和外觀的關鍵步驟。面漆的顏色和光澤度根據產品設計要求而定，可選擇高光、啞光等不同效果的涂料。面漆噴涂同樣要控制好各項參數，保證涂層顏色均勻、光澤一致，面漆厚度一般在 20 - 40 微米。為了使涂層達到更好的效果，一些高檔產品還會進行罩光漆噴涂，增加涂層的耐磨性和耐候性，提升產品外觀質感。

　　After the primer dries, the intermediate coating is sprayed immediately. The intermediate coating mainly plays a role in filling and leveling, further improving the flatness and fullness of the coating, while enhancing the protective performance of the coating. The intermediate coating usually has good polishing properties. After spraying and drying, it needs to be polished to eliminate surface defects such as particles and flow marks, creating a smooth surface for topcoat spraying. The polished workpiece enters the topcoat spraying process, which is a key step in endowing the workpiece with the final color and appearance. The color and glossiness of the topcoat are determined according to the product design requirements, and different effects of coatings such as high gloss and matte can be selected. The spraying of topcoat should also control various parameters to ensure uniform color and consistent gloss of the coating. The thickness of the topcoat is generally between 20-40 microns. In order to achieve better coating effects, some high-end products also undergo topcoat spraying to increase the wear resistance and weather resistance of the coating, and enhance the appearance and texture of the product.

　　固化干燥：讓涂層 “定型”

　　Curing and drying: shaping the coating

　　噴涂完成后的工件，需要經過固化干燥環節，使涂料中的樹脂等成分發生交聯反應，形成堅硬、牢固的涂層。固化干燥方式主要有自然干燥和加熱干燥。自然干燥適用于干燥速度較慢、對溫度敏感的涂料，但所需時間較長，生產效率較低。在工業涂裝流水線中，更多采用加熱干燥，如通過隧道式烘干爐、紅外線烘干等方式。烘干過程中，要嚴格控制溫度和時間，不同類型的涂料固化條件不同，溫度過高或時間過長可能導致涂層變色、開裂，溫度過低或時間不足則會使涂層固化不完全，影響性能。一般來說，烘干溫度在 60 - 200 攝氏度之間，時間根據涂層厚度和涂料特性而定，從幾分鐘到幾十分鐘不等。

　　After spraying, the workpiece needs to go through a curing and drying process to cause cross-linking reactions of resin and other components in the coating, forming a hard and firm coating. The main methods of solidification drying are natural drying and heating drying. Natural drying is suitable for coatings with slow drying speed and temperature sensitivity, but it requires a longer time and has lower production efficiency. In industrial painting assembly lines, heating drying is more commonly used, such as through tunnel drying ovens, infrared drying, and other methods. During the drying process, temperature and time should be strictly controlled. Different types of coatings have different curing conditions. Excessive temperature or time may cause discoloration and cracking of the coating, while insufficient temperature or time may result in incomplete curing of the coating, affecting its performance. Generally speaking, the drying temperature is between 60-200 degrees Celsius, and the time depends on the thickness and characteristics of the coating, ranging from a few minutes to several tens of minutes.

　　質量檢驗與后處理：把好成品 “關卡”

　　Quality inspection and post-processing: ensuring the quality of finished products

　　經過固化干燥的工件，進入質量檢驗環節。檢驗人員會對涂層的外觀、厚度、附著力、硬度等指標進行全面檢測。通過目視檢查涂層表面是否平整、有無流掛、氣泡、色差等缺陷；使用測厚儀測量涂層厚度是否符合標準；通過劃格試驗、沖擊試驗等方法檢測涂層附著力和硬度。對于不合格的產品，需進行返工處理，如補漆、重新打磨等。合格的工件還可能根據需要進行后處理，如貼標、包裝等，最后成品下線，完成整個涂裝流程。

　　After solidification and drying, the workpiece enters the quality inspection process. Inspectors will conduct a comprehensive inspection of the appearance, thickness, adhesion, hardness, and other indicators of the coating. Visually inspect the coating surface for flatness, sagging, bubbles, color differences, and other defects; Use a thickness gauge to measure whether the coating thickness meets the standard; Detect coating adhesion and hardness through methods such as grid test and impact test. For non-conforming products, rework is required, such as repainting, re polishing, etc. Qualified workpieces may also undergo post-processing as needed, such as labeling, packaging, etc., and finally the finished product is taken offline to complete the entire painting process.

　　工業涂裝流水線的每一個操作步驟都凝聚著技術與經驗，從預處理到成品下線，這套嚴謹?shù)牧鞒檀_保了工件在獲得美觀外觀的同時，擁有可靠的防護性能，為工業產品的品質和價值提升提供了有力保障。

　　Every operation step of the industrial painting assembly line embodies technology and experience, from pre-treatment to finished product production. This rigorous process ensures that the workpiece has reliable protective performance while obtaining a beautiful appearance, providing strong guarantees for the quality and value improvement of industrial products.
